Fox Transfer Post Factory Series

Regular price
$541.00
Sale price
$421.00
Quantity must be 1 or more
Sold Out - Notify Me When Available
925-01-142
Ships within USA only

Pickup Not Available in our Bellingham, WA shop Store Info

  • The Lost Co

    Pickup Not Available in our Bellingham, WA shop

    2106 Pacific Street
    Ste 102
    Bellingham WA 98229
    United States

    +1 (360) 306-8827


Routing: Internal
Lower Coating: Powdercoat Black
Upper Coating: Kashima Coat

MPN:925-01-142
//
UPC:821973383736
Liquid error (snippets/product-form.liquid line 26): include usage is not allowed in this context .


Specs
-
Patent-pending clamp design dramatically reduces stack height

-Proven Transfer intervals with even easier serviceability than 2020 model
-25g lighter than 2020 model
-New Lightweight under-bar 1x lever design, or existing 2x lever

Reduced overall length and insertion depth (numbers below compared to 2020 Transfer)

175mm: 30.6 mm shorter, 8.6mm insertion reduction
150mm: 38.7 mm shorter, 15.5mm insertion
125mm: 43.5 mm shorter, 20.3mm insertion reduction
100mm: 48.4 mm shorter, 25.2mm insertion




Dimensions (In millimeters)

Drop Total Length Stack Height Insertion Length* Minimum Insertion

100mm

308.6

138.3

170.3

100

125mm

363.5

163.3

200.2

100

150mm

418.3

188.2

230

100

175mm

475.1

213.2

261.9

100

200mm

530.7

238.9

291.8

150


          *not including actuator, which is 28mm
